Marking speed | 2-5 characters(2x2mm)/s |
Stroke Frequency | 300times/s |
Marking depth | 0.01 to 1mm (Vary to the material) |
Marking contents | Alphanumeric info, Data Matrix or dot matrix 2D codes, Shift codes, Barcode, Serial Number, Date, VIN Code, Time, Letter, Figure, Logo, Graphics and etc. |
Stylus Pin Hardness | HRA92/HRA93 |
Marking area | 80x40mm,130x30mm,140x80mm,200x200mm |
Dimensions | 45x45x55cm |
Marking materials | below HRC60 metallic and nonmetallic materials , above HRC60 need special stylus |
Repeat accuracy | 0.02-0.04mm |
Power | 300W |
Work voltage | AC 110V 60HZ or AC220V 50HZ |
Compressed Air( Pneumatic Air) | 0.2-0.6Mpa |
Connection | USB and RS-232 |
Controller | a. 7"LCD touch screen controller b. windows 7&windows XP |
Power type | a.Pneumatic b.Electric |
Marking directions | up, down, left, right, and the circular arc surface marking |
Gross weight | 12KG |
